Appendices
A-146
CJ2 CPU Unit Software User’s Manual
A485 --- EM Bank 18
Designation
This word stores a fixed code that is used to specify the area
when an address is specified as a parameter for a function block
instead of an input-output variable (VER_IN_OUT). This code is
used only by the OMRON FB Library. Do not change the contents
of this word.
Fixed value
is set.
Fixed
value is
set.
---
A10001
to
A10003
--- Manufacturing
Lot Number
The manufacturing lot number of the CPU Unit is stored as BCD
data. Hardware can be identified by referring to this area.
hex
A10000.00 to A10000.07: 00 hex
A10000.08 to A10000.15: 00 hex
A10001.00 to A10000.07: 00 hex
A10001.08 to A10001.15: Day (01 to 31)
A10002.00 to A10002.07: Month (01 to 12)
A10002.08 to A10002.15: Year (00 to 09)
A10003.00 to A10003.07: 00 hex
A10003.08 to A10003.15: 00 hex
--- --- ---
A10100 A10100.00 Synchronous
Unit Operation
Servicing Flag
ON while synchronous unit operation is being performed.
ON: Synchronous unit operation being performed
OFF: Synchronous unit operation not being performed
Cleared Cleared Refreshed when the
synchronous signal
turns ON the sec-
ond time after
power is turned ON
or Unit is restarted.
A10101 --- Synchronous
Input Data
Refresh Error
Code
This word contains 0001 hex when the CPU Unit fails to receive
synchronous input data from a Synchronous Unit within the spec-
ified time.
0001 hex: Error
0000 hex: Normal
Cleared Cleared When synchronous
data is refreshed.
A10102 --- Synchronous
Operation Cycle
Time
This word contains the synchronous operation cycle time set in
the PLC Setup.
Retained Retained When power is
turned ON or the
Unit is restarted.
A10120
and
A10121
--- Pulse Output 0
Frequency
Contains the frequency of pulse output 0 when tracing pulse out-
put 0 with data tracing.
Valid only when the data tracing parameters are set.
--- Cleared ---
A10122
and
A10123
--- Pulse Output 1
Frequency
Contains the frequency of pulse output 1 when tracing pulse out-
put 1 with data tracing.
Valid only when the data tracing parameters are set.
--- Cleared ---
A10124
and
A10125
--- Pulse Output 2
Frequency
Contains the frequency of pulse output 2 when tracing pulse out-
put 2 with data tracing.
Valid only when the data tracing parameters are set.
--- Cleared ---
A10126
and
A10127
--- Pulse Output 3
Frequency
Contains the frequency of pulse output 3 when tracing pulse out-
put 3 with data tracing.
Valid only when the data tracing parameters are set.
--- Cleared ---
A10128
and
A10129
--- High-speed
Counter 0 Range
Comparison
Condition 1 to 32
In-range Flags
These flags indicate whether the PV is within any of the one to 32
ranges when high-speed counter 0 is being operated in range-
comparison mode with upper and lower limits. The In-range
Flags, however, will be ON whenever the comparison value is
within the range regardless of the whether the high-speed counter
is set to execute the interrupt task when the range is entered or
left.
OFF: Not in range, ON: In range
Bits 00 to 15 in the lower word correspond to ranges 1 to 16. Bits
00 to 15 in the upper word correspond to ranges 17 to 32.
Cleared Cleared • Refreshed each
cycle during over-
seeing process.
• Refreshed when
comparison is
executed for 1 to
32 ranges.
• Refreshed when
PRV(881) instruc-
tion is executed to
read the results of
range compari-
son.
• Refreshed when
INI(880) instruc-
tion is executed to
change PV or ring
counter maxi-
mum value.
• Reset
Address
Name Function
Status
after mode
change
Status at
startup
Write timing/
Related flags, set-
tings
Words Bits
