20
NV-Designer Window Names and Menus Section 3-2
View Redraw Redraws the contents of the screen that is being edited.
Grid Sets the grid on base screens edited with the NV-Designer.
Toolbar Displays and hides the toolbar.
Status bar Displays or hides the status bar.
Graphic bar Displays and hides the graphic bar.
Zoom 400% Changes the magnification of the base screen that is being
edited.
200%
100%
75%
50%
Zoom Box Displays a Zoom Box so that detailed sections can be drawn
and fine adjustments can be made to positions when creat-
ing a base screen.
Parts No. Displays the parts numbers of all parts on the base screen
that is being edited.
Parts Attribute Displays the attributes of all parts on the base screen that is
being edited.
Status OFF Places a bit switch, function switch, or lamp on the screen in
OFF status.
ON Places a bit switch, function switch, or lamp on the screen in
ON status.
Language No. Changes the language number when switching the display
language is being used.
Address Cross Refer-
ence
The system memory used for communications with the PLC
and the communications addresses used by parts on the
screen are displayed in a list.
Menu Submenu/Command Description
