Omron OMNUC G Series User Manual

2-51
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Note1. The standard models have a straight shaft.
Note2. Models with a key and tap are indicated with "J" at the end of the model number (the suffix shown in the
box). (Example: R88G-HPG32A051K0BJ)
Note3. Applicable for the servomotors with key, if the key is removed.
Model
Dimensions (mm)
LM LR C1 C2 D1 D2 D3 D4 D5 E F1 F2
1 kW
1/5 R88G-HPG32A051K0B 104 133 120
122 dia.
135 100 115 114 8498 12.5 35
1/11 R88G-HPG32A111K0B 104 133 120
122 dia.
135 100 115 114 8498 12.5 35
1/21 R88G-HPG32A211K0B 104 133 120
122 dia.
135 100 115 114 8498 12.5 35
1/33 R88G-HPG32A331K0B 104 133 120
122 dia.
135 100 115 114 8498 12.5 35
1/45 R88G-HPG50A451K0B 123 156 170
170 dia.
190 100 165 163 122 103 12.0 53
1.5 kW
1/5 R88G-HPG32A052K0B 110 133 120
135 dia.
135 115 115 114 8498 12.5 35
1/11 R88G-HPG32A112K0B 110 133 120
135 dia.
135 115 115 114 8498 12.5 35
1/21 R88G-HPG32A211K5B 110 133 120
135 dia.
135 115 115 114 8498 12.5 35
1/33 R88G-HPG50A332K0B 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
1/45 R88G-HPG50A451K5B 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
2 kW
1/
5 R88G-HPG32A052K0B 110 133 120
135 dia.
135 115 115 114 8498 12.5 35
1/11 R88G-HPG32A112K0B 110 133 120
135 dia.
135 115 115 114 8498 12.5 35
1/21 R88G-HPG50A212K0B 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
1/33 R88G-HPG50A332K0B 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
3 kW
1/5 R88G-HPG32A053K0B 107 133 120 130
130 135 145 115 114 8498 12.5 35
1/11 R88G-HPG50A113K0B 123 156 170
170 dia.
190 145 165 163 122 103 12.0 53
1/21 R88G-HPG50A213K0B 123 156 170
170 dia.
190 145 165 163 122 103 12.0 53
4 kW
1/5 R88G-HPG32A054K0B 129 133 120 130
130 135 145 115 114 8498 12.5 35
1/11 R88G-HPG50A115K0B 149 156 170 130
130 190 145 165 163 122 103 12.0 53
5 kW
1/5 R88G-HPG50A055K0B 149 156 170 130130 190 145 165 163 122 103 12.0 53
1/11 R88G-HPG50A115K0B 149 156 170 130
130 190 145 165 163 122 103 12.0 53
