Omron OMNUC G Series

2-55
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Decelerators for 1,000-r/min Servomotors
Note1. The standard models have a straight shaft.
Note2. Models with a key and tap are indicated with "J" at the end of the model number (the suffix shown in the
box). (Example: R88G-HPG32A05900TBJ)
Note3. Applicable for the servomotors with key, if the key is removed.
Model
Dimensions (mm)
LM LR C1 C2 D1 D2 D3 D4 D5 E F1 F2
900 W
1/5 R88G-HPG32A05900TB 129 133 120 130130 135 145 115 114 8498 12.5 35
1/11 R88G-HPG32A11900TB 129 133 120 130130 135 145 115 114 8498 12.5 35
1/21 R88G-HPG50A21900TB 149 156 170 130130 190 145 165 163 122 103 12.0 53
1/33 R88G-HPG50A33900TB 149 156 170 130130 190 145 165 163 122 103 12.0 53
2 kW
1/5 R88G-HPG32A052K0TB 129 133 120 180180 135 200 115 114 8498 12.5 35
1/11 R88G-HPG50A112K0TB 149 156 170 180180 190 200 165 163 122 103 12.0 53
1/21 R88G-HPG50A212K0TB 149 156 170 180180 190 200 165 163 122 103 12.0 53
1/25 R88G-HPG65A255K0SB 231 222 230 180180 260 200 220 214 168 165 12.0 57
3 kW
1/5 R88G-HPG50A055K0SB 149 156 170 180180 190 200 165 163 122 103 12.0 53
1/11 R88G-HPG5
0A115K0SB 149 156 170 180180 190 200 165 163 122 103 12.0 53
1/20 R88G-HPG65A205K0SB 231 222 230 180180 260 200 220 214 168 165 12.0 57
1/25 R88G-HPG65A255K0SB 231 222 230 180180 260 200 220 214 168 165 12.0 57
4.5 kW
1/5 R88G-HPG50A054K5TB 149 156 170 180180 190 200 165 163 122 103 12.0 53
1/12 R88G-HPG65A127K5SB 254.5 222 230 180180 260 200 220 214 168 165 12.0 57
1/20 R88G-HPG65A204K5TB 254.5 222 230 180180 260 200 220 214 168 165 12.0 57
6 kW
1/5 R88G-HPG65A057K5SB 184.5 222 230 180180 260 200 220 214 168 165 12.0 57
1/12 R88G-HPG65A127K5SB 254.5 222 230 180180 260 200 220 214 168 1
65 12.0 57
