Panasonic VF100 - P107: Proportional Gain [Kp]; P108: Integral Time [Ti]; P109: Derivative Time [Td]; P110: Control Cycle [Ts];P111: PID Target Value

* "0000" is setting that the integral control is to
be disabled.
・ Parameter P107~109 settings are used as parameter of PID control.
・ Parameter P110 setting performs cycle under PID control.
・ When Parameter P004 = "1" or "7", setting value (SP) is set with parameter P111.
P107：Proportional gain [Kp]
P108：Integral time [Ti]
P109：Derivative time [Td]
P110：Control cycle [Ts]
P111：PID target value
Used to set proportional gain, integral time, derivative time, control cycle and PID target value
required in PID control.
[Parameter P107: Proportional gain (Kp)]
0.1 to 1000
Data setting range
0000・0.1 to 3600
Data setting range (s)
0000・0.1 to 3600 Data setting range (s)
0.01 to 60.0
Data setting range (s)
0.0・0.1 to 100.0
Data setting range (%)
[Parameter P108: Integral time (Ti)]
[Parameter P109: Derivative time (Td)]
[Parameter P110: Control cycle (Ts)]
[Parameter P111: PID target value]
* "0000" is setting that the derivative control is
to be disabled.
115
・PID control select
・Input signal select of measured value (PV)
・Bias/gain setting for measured value (PV)
・Setting signal select of setting value (SP)
・Bias/gain setting for setting value (SP)
・ Upper/lower clamp setting for output frequency
・PID control changeover input setting
⇒" P124: Analog input function select 2"
⇒"P125: Analog input signal select 2"
⇒"P126: Bias frequency setting 2"
⇒"P004: Frequency setting signal"
⇒"P102: Bias/gain function select"
⇒"P099: Lower/upper frequency clamp",
"P100: Lower/upper frequency clamp"
⇒"P036~040: SW1~5 function select"
Related
parameters
"P127: Gain frequency setting 2"
"P103: Bias frequency setting"
"P104: Gain frequency setting"
