P124：Analog input function select 2
Control function of analog input terminal 2 (control circuit terminal No.16) can be selected.
[Frequency setting signal 2]
・ SW function select is set to frequency signal changeover input. Turn the set SW ON/OFF for
switching frequency setting command to frequency setting signal 1 or 2.
(SW function select : parameter P036~P040 )
[Feedback signal under PID control]
・ Analog input terminal 2 can be used as feedback signal under PID control (Measured value PV).
・ When applying PID control, refer to details on parameters P106~P111.
・ Input OFF into SW : frequency setting signal 1,
Input ON into SW: frequency setting signal 2
・ Analog input terminal 2 can be used as frequency setting signal 2.
・ For using PID control effectively, parameter (P124) is required to be set to "1".
Feedback signal under PID control
(Measured value PV)
1
Frequency setting signal 20
Details
Data setting
value
123
P004, P036～P040
P106～P111, P125～P127
相关
参数
Related
parameters
