30
Press the RUN button.
The run state will be entered, but
as the frequency setting dial is
set to Min., the OV stop state will
be entered.
Changing
the rotation
direction
Run command
Press the UP button.
(The main display will flicker.)
Press the SET button to set the
data. (Return to operation status
display mode)
[Continued from previous page.]
Gradually turn the frequency setting
dial clockwise, and then motor will
start to run. When "25.0" is displayed,
the motor is operating at 25Hz.
Stopping operation
Press the STOP button.
The motor will start to decelerate
and will stop.
Frequency
setting
Stop command
Use the same procedures as "Changing the rotation direction" explained above. In this case, when the
SET button is pressed last the display will change to the "operation state display mode", the motor will
decelerate and then will start rotating in the reverse direction.
[Example for changing the rotation direction during operation]
RUN
STOP
SET
To Next Page
