Panasonic VF100 - P130: Motor Capacity; P131: No. of Motor Poles

Note
・ Vector control is valid only when "P128: Carrier frequency" is in the range of 2.5kHz~10.0kH.
When carrier frequency is set to 0.8kHz~1.6kHz and "P129: Vector control select" is set to "1"
(vector control), setting value of carrier frequency will change to 2.5kHz automatically.
P130：Motor capacity
Used to set the capacity required to drive the motor when vector control is used.
・ After setting data is changed, data of "P133: Voltage compensation constant" and "P134: Slip
compensation frequency" will automatically change to the motor constant recommended by
our company.
2.2kW2.2
0.75kW0.7
0.4kW0.4
1.5kW1.5
3.7kW3.7
Motor capacity Data setting value
Note
P131：No. of motor poles
Used to set No. of poles required to drive the motor when vector control is used.
・ After setting data is changed, data of "P133: Voltage compensation constant" and "P134: Slip
compensation frequency" will automatically change to motor constant recommended by our
company.
6 poles6
4 poles4
2 poles2
No. of motor poles Data setting value
Note
・ When vector control is selected, output frequency is in the range of 1Hz~120Hz.
129
P128
P130～P134
相关
参数
Related
parameters
P129
P131～P134
相关
参数
Related
parameters
P129～P130
P131～P134
相关
参数
Related
parameters
