Panasonic VF100 - R311: Operation Status Monitor; R312: Operation Control Status Monitor

"R311□: Operation status monitor"
1 : Automatic tuning operation state of motor constant
0 : Normal operation state
Automatic tuning function
of motor constant
R311A
Detect current (or more) signal R3116
Frequency detect (P94)R3115
Frequency detect (P93)R3114
Overload alarmR3113
1 : Fault state
0 : Normal state
Fault state
R311B
1 : Timer's operation state
0 : Normal operation state
Timer's operation function
R3119
1 : PID automatic tuning operation state
0 : Normal operation state
PID automatic tuningR3118
Detect current (or less) signal R3117
1 : ON
0 : OFF
Arrival signalR3112
1 : Runs
0 : Stops
Reverse operation statusR3111
1 : Runs
0 : Stops
Operation statusR3110
DetailsNameRelay No.
It indicates the operation status of the inverter.
"R312□: Operation control status monitor"
During the operation of timerR3127
SW5 command stateR3126
During the operation of pulse input
R3128
SW4 command stateR3125
SW3 command stateR3124
SW2 command stateR3123
SW1 command stateR3122
Reverse run command state
R3121
1 : With command
0 : No command
Run command state
R3120
DetailsName
Relay No.
It indicates the operation control status of the inverter.
