Panasonic VF100 - Example: Mode of Timers One Cycle Operation

P045=3
P045=4
T1 T2 T3
T4
T5 T6
T7
T8
A1
A1 A1 D1
D1/A1
A1 D1
D1/A1
D1
①
②
③
④
⑤
⑥
⑦
⑧
T1 T2 T3
T4
T5 T6
T7
T8
A1
A2 A3 D4
D1/A1
A1 D1
D1/A1
D1
00
0
0 11 1
0
Rotation
direction
Forward runReverse run
Setting value
"112"
(H’70)
* Setting value of "P069: Continuous mode of timer's operation" is "0".
Setting value of "P067: Rotation direction of timer's operation" is "112".
［Example: mode of timer's one cycle operation］
Note
・During timer's operation, if stop command is input, the operation will be stopped immediately
even in cycle operation.
・During timer's operation, forward run/reverse run command of the operation panel, external
control and communication is invalid.
After the timer runs one cycle for times set with parameter "P068: Continuous times of timer's
operation" , "tEnd" will be displayed. Input stop command when "tEnd" is being displayed, "0000"
will be returned to (operation state mode).
"P068: Continuous times of timer's
operation"
Setting times
End of timer's operation
Panel: STOP SW
External control: stop command
(terminal No.2 is turned OFF)
Communication: stop command
96
P001, P002, P036～P041
P046～P052, P061～P078
Related
parameters
