Panasonic VF100 - Rated Specifications; Standard Specifications

16. Specifications
Three-phase 400V input type
10.46.98.7 Note1)3.7AVF100-0374
6.44.45.52.2AVF100-0224
4.83.24.01.5AVF100-0154
2.6
2.0
1.9
1.5
1.41.72.10.75AVF100-0074
Mass
(kg)
Power supply
capacity
(kVA) Note3)
Rated output
capacity
(kVA) Note2)
Rated output
current
(A)
Applied motor
output
(kW)
Product No.
Note1)
・10.0 kHz: (rated output current) ×0.9 ＝ 7.83A
Rated output capacity is specified for output voltage of 460V AC.
Power supply capacity depends on power supply impedance. It should equal or exceed
the capacity specified above.
16-1. Rated Specifications
Continuous operation at 323V AC or more.
Continuous operation at less than 323V AC for 15ms
Instantaneous voltage
drop resistance capacity
±5% of rated input frequency
Tolerable frequency
variations
+10%, -15% of rated AC input voltage
Tolerable voltage
variations
Three -phase, 380 to 460V AC 50/60Hz
Number of phases,
voltage, frequency
Input power supply
150% of rated output current for 1 minute
Overload current rating
Three-phase, 380 to 460V AC
(proportional to power supply voltage)
Rated voltage
Rated output
0.75～3.7kW Applied standard motor output (kW)
16-2. Standard Specifications
Three-phase 400V input type
202
Rated output current of 3.7kW is specified for carrier frequency of 7.5kHz or less.
At 10.0 kHz, rated output current is used after it has been reduced by 10%.
Note2)
Note3)
