Panasonic VF100 - R309: Control Terminal State Monitor (Input Signal); R310: Control Terminal State Monitor (Output Signal); Supplementary Explanation of Communication Monitor Function

"R309□：Control terminal state monitor (input signal)"
SW5 signal input stateR3096
SW4 signal input stateR3095
SW3 signal input stateR3094
SW2 signal input stateR3093
SW1 signal input stateR3092
Reverse run signal input state
R3091
1 : Terminal is ON (closed).
0 : Terminal is OFF (opened).
Operation signal input state
R3090
DetailsNameRelay No.
It indicates the input states of the control terminals No.2~8.
"R310□：Control terminal state monitor (output signal)"
1 : TR output signal is ON
0 : TR output signal is OFF
TR1 output signalR3100
1 : TR output signal is ON
0 : TR output signal is OFF
TR2 output signalR3101
1 : RY output signal is ON (energized).
0 : RY output signal is OFF (not energized).
RY output signalR3102
DetailsNameRelay No.
It indicates the output states of TR1, TR2 and RY output terminals.
12-9.1 Supplementary Explanation of Communication Monitor Function
184
