・ The frequency for applying the DC brake is set with parameter P033 stop frequency during
forward run/reverse run operation.
・ "P033: Stop frequency during forward run/reverse run operation" is valid only when applying
DC brake during forward run/reverse run operation.
(It's valid when P034 is set to value other than 0000.)
・ DC brake during stopping is set with parameters "P030: Stop frequency", "P031: DC brake
time" and "P032: DC brake level".
Note
Stop frequency
during forward
run/reverse run
operation (P033)
Forward
Reverse
Operation
frequency
Brake time during
forward run/reverse
run operation (P034)
[During forward run/
reverse run operation]
0
81
