Acceleration and
deceleration link multi
speed frequency
operation function
2
nd
, 3
rd
and 4
th
acceleration and
deceleration
operation function
Multi speed frequency
operation function
P045=2P045=1P045=0
SW4
(Note1)
SW3
(Note1)
SW2
(Note1)
SW1
(Note1)
1
st
acceleration
and deceleration
4
th
acceleration
and deceleration
3
rd
acceleration
and deceleration
2
nd
acceleration
and deceleration
1
st
acceleration
and deceleration
16
th
speed
15
th
speed
14
th
speed
13
th
speed
12
th
speed
11
th
speed
10
th
speed
9
th
speed
8
th
speed
7
th
speed
6
th
speed
5
th
speed
4
th
speed
3
rd
speed
2
nd
speed
1
st
speed
Frequency
1
st
acceleration
and deceleration
4
th
acceleration
and deceleration
3
rd
acceleration
and deceleration
2
nd
acceleration
and deceleration
1
st
acceleration
and deceleration
Acceleration
and deceleration
time
1st speed
Frequency
1st acceleration
and deceleration
Acceleration
and deceleration
time
16
th
speed
15
th
speed
14
th
speed
13
th
speed
12
th
speed
11
th
speed
10
th
speed
9
th
speed
8
th
speed
7
th
speed
6
th
speed
5
th
speed
4
th
speed
3
rd
speed
2
nd
speed
1
st
speed
Frequency
OFFOFFONON
OFFONOFFOFF
OFFONOFFON
OFFONONOFF
OFFONONON
ONOFFOFFOFF
ONOFFOFFON
ONOFFONOFF
ONOFFONON
ONONOFFOFF
ONONOFFON
ONONONOFF
ONONONON
OFFOFFONOFF
OFFOFFOFFON
OFFOFFOFFOFF
(Note 1) Any four SW function among 1~5 are set to "0" (multi speed SW input function), 4 SW
in order are valid as multi speed command SW from the smaller SW No.
＜Example＞ When SW1, SW2, SW4 and SW5 are set to multi speed SW input function,
the position of SW3 in the above table will change to SW4 and the position
of SW4 will change to SW5.
［Setting value "1": example for multi speed frequency operation function］
The 16 frequency can be selected, switched and controlled with the four button signals SW2~5.
(1
st
speed: setting signal of P004, 2
nd
~16
th
speed: setting frequency of P046~P060)
・Any four buttons among SW1~5 are set to multi speed function buttons.
(Value of P036~P040 is set to "0".)
・In this function, using one button to input 2 speed, two buttons to input 4 speed and three buttons to
input 8 speed.
・When 2
nd
~16
th
speed frequency (P046~P060) is set to "0000" and this multi speed frequency
is selected, the inverter stops (0V stop).
