Note
・1
st
speed is command value of frequency setting signal set with parameter P004.
・2
nd
~16
th
speed frequency are the frequency set with parameters P046~P060.
2
nd
~4
th
acceleration and deceleration time are set with parameters P061~P066.
・1
st
acceleration time is the acceleration time set with parameter P001.
1
st
deceleration time is the deceleration time set with parameter P002.
ON
1 speed
Run
command
SW1
SW2
ON
ON
ON
ON
2 speed
3 speed
4 speed
3 speed
2 speed
1
st
acceleration
3
rd
acceleration
4
th
acceleration
3
rd
deceleration
2
nd
deceleration
2
nd
deceleration
1
st
deceleration
［Setting value "3": Example for acceleration and deceleration link multi speed frequency operation function］
Using two SW button signals among 2
nd
, 3
rd
and 4
th
speed to link 2
nd
, 3
rd
and 4
th
acceleration and
deceleration.
・Any two buttons among SW1~5 are set to multi speed function buttons.(Value of P036~P040
is set to "0".)
＜When SW1 and Sw2 are set to multi speed SW input function,＞
94
Output frequency
P036～P041
P046～P066
Related
parameters
