LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Troubleshooting Chart
Section Menu Section Contents Back Index
104
5
SpO2/SpCO/SpMet Features Saturation reading missing or out of
tolerance.
SpO2 displays XXX in the SpO2 region
of the display with the Service LED
OFF (review diagnostic log).
Verify test setup and retry test.
Retry test with another test subject.
Check finger sensor; replace if necessary.
Possible device configuration setup error.
Possible A16 SpO2 Module failure.
Possible W22 SpO2 Connector Cable failure.
Possible A06 OEM PCB failure.
SpO2 displays XXX in the SpO2 region
of the display with the Service LED ON
See error code 900e in Table 5.12 on page 129 for assistance.
NIBP Feature NIBP displays XXX in the NIBP region
of the display with the Service LED
OFF (review diagnostic log).
Perform NIBP leakage test.
Possible blockage or kink in tubing between NIBP connector and NIBP
module.
Possible A21 NIBP module failure.
NIBP displays XXX in the NIBP region
of the display with the Service LED ON
See error code 9119 in Table 5.12 on page 129 for assistance.
Temperature Feature TEMP: ACCURACY OUTSIDE LIMITS
message is displayed, and the
temperature value is “XXX”
Temperature calibration required; verify test setup and test equipment
accuracy requirements.
Possible temperature adapter cable failure.
Possible A01 System PCB failure.
Table 5.1— Corrective Actions (Continued)
Area Observed Symptom Suggested Corrective Action
