OEM PCB/SpO2 (W21) Module Cable Replacement
OEM PCB/SpO2 Module cable replacement consists of the following procedures:
• Removing the OEM PCB/SpO2 Module Cable (W21) (p. 343)
• Installing the OEM PCB/SpO2 Module Cable (W21) (p. 343)
Figure 8.114—OEM/SpO2 cable screw location
screw location
OEM/SpO2 Cable
