Invasive Pressure Connector Assembly (W33) Replacement
Section Menu Section Contents Back Index
355
8
Invasive Pressure Connector Assembly (W33) Replacement
Invasive pressure connector assembly replacement consists of the following procedures:
• Removing the Invasive Pressure Connector Assembly (W33) (p. 356)
• Installing the Invasive Pressure Connector Assembly (W33) (p. 356)
Figure 8.120—Invasive pressure parts and screw locations
IP wire
harness
IP gaskets
screws
screws
screws
