Physio Control LIFEPAK 15 - NIBP Connector Replacement

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
NIBP Connector Replacement
Section Menu Section Contents Procedures Back Index
306
8
NIBP Connector Replacement
NIBP connector replacement consists of the following procedures:
• Removing the NIBP Connector (p. 307)
• Installing the NIBP Connector (p. 308)
Figure 8.100—NIBP connector and nut location
O ring
hex nut
NIBP connector
NIBP tubing
NIBP connector
orientation
