LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
NIBP Connector Replacement
Section Menu Section Contents Procedures Back Index
308
8
Installing the NIBP Connector
Refer to Figure 8.100 on p. 306.
To install the NIBP connector into the parameter bezel (rear case—refer to Inside Rear Case Diagrams (p. 228)):
NOTE: When installing a new NIBP connector, use NIBP Connector Repair Kit (MIN 3305431-022) (p. 510).
1. Install the connector (3207033-001) by installing the fitting nut on the back side of the bezel. Ensure the O ring seal is on the
NIBP connector (torque to 10.0 in-lb using a 1/2" deep socket) (see Figure 9.11 on p. 393 for NIBP connector orientation).
2. Connect the NIBP tube (3012180-02) to the NIBP connector (3207033-001).
NOTE: If the NIBP tube has been previously disconnected/reconnected from the fitting, the tube end should be trimmed
to maintain an airtight seal.
3. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
4. Install the system/therapy PCB assembly as described in Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239).
5. Reassemble the case as described in Reassembling the Case (p. 184).
