LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Tools List
Section Menu Section Contents Procedures Back Index
176
8
Tools List
The suggested list of tools for the LIFEPAK 15 monitor/defibrillator replacement procedures is as follows:
• Static-dissipative mat and wrist strap
• Anti-static rack and/or conductive bags
• Capacitor discharge tool (information about Capacitor Discharge Tool (p. 177))
• Torque screwdriver(s)—required torque settings are 2.0, 4.0, 6.8, and 10.0 in-lb
• Point 0 power drive bit (P0)- Phillips tip for 2-56 screws
• Point 1 power drive bit (P1)- Phillips tip for 4-40 screws (shaft length of 2” and 6”)
• Point 2 power drive bit (P2)- Phillips tip for 6-32 screws (shaft length of 6”)
• T10 torx power drive bit
• T15 torx power drive bit
• 4 mm modified thin wall socket for battery pins (Physio-Control tool #3300955)
• 1/4” socket
• 1/2” deep socket
• 9/16” deep socket
• 3/4” modified deep socket (Physio-Control tool #3305448)
• 3/8” nutdriver
• Small, slotted screwdriver for label removal
• Diagonal cutter
• Needle nose pliers
• 1.5” (hard) putty knife
• See PIP–Test Equipment Requirements and TCP–Test Equipment Requirements for additional test tools required for
performance testing
Torque in-lb 2.0 4.0 6.8 10.0
Torque in-oz 32 64 108.8 160
Torque cNm 22.5 45 77 113
