LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Summary of Replacement Procedures
Section Menu Section Contents Procedures Back Index
170
8
Summary of Replacement Procedures
Replacement procedures are referenced and linked in the inside front case diagram (see Inside Front Case Diagram (p. 189)) and inside rear case
diagrams (see Inside Rear Case Diagrams (p. 228)). Most activities start with disassembling the case (see Disassembling the Case (p. 181)).
NOTE: The “Procedures” link in the button bar at the bottom of each page returns you to this page to select the appropriate replacement
procedure.
NOTE: To simplify cable referencing, the cable number only is sometimes used in the replacement procedures. For example, the power/system
PCB cable (W01) may be referred to in procedures as the W01 cable.
Inside Front Case Part Replacement Procedures
Choose from the following inside front case replacement procedures (in alphanumerical order):
• Backlight PCB (A08) Replacement (p. 195)
• Backlight/Interface PCB Cable (W06) Replacement (p.
213)
• Display Shield Replacement (p. 202)
• Front Case Replacement (p. 208)
• Interface PCB (A05) Replacement (p. 190)
• LCD Display Assembly (A11) Replacement (p. 204)
• LCD Display Assembly/Interface PCB Cable (W18)
Replacement (p. 226)
• Main Keypad (A10) Replacement (p. 200)
• Main Keypad/Interface PCB Cable (W13)
Replacement (p. 217)
• Printer Assembly/Interface PCB Cable (W16)
Replacement (p. 221)
• Printer Assembly/Chassis Ground Cable (W19)
Replacement (p. 227)
• Printer Control Keypad (A09) Replacement (p. 198)
• Printer Control Keypad/Interface PCB Cable (W12)
Replacement (p. 216)
• Speaker Assembly (W17) Replacement (p. 223)
• Speed Dial Assembly (W15) Replacement (p. 218)
• System/Interface PCB Cable (W04) Replacement (p.
212)
• Therapy Connector Cable (W11) Replacement (p.
214)
