Physio Control LIFEPAK 15 - System (A01);Therapy (A04) PCB Assembly Replacement

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
System (A01)/Therapy (A04) PCB Assembly Replacement
Section Menu Section Contents Procedures Back Index
232
8
System (A01)/Therapy (A04) PCB Assembly Replacement
The system/therapy PCB assembly is removed as a unit and then separated. Refer to System/Therapy PCB Assembly Diagrams and Parts List (p.
387) and Figure 9.9 (p. 388) for diagrams of this assembly. See Figure 9.24 on p. 446 for a connection diagram of the therapy PCB and Figure
9.22 on p. 444 for a connection diagram of the system PCB.
Replacement consists of the following procedures:
• Removing the System (A01)/Therapy (A04) PCB Assembly (p. 233)
• Separating the System PCB (A01) (p. 244)
• Replacing the System PCB (A01) (p. 246)
• Separating the Therapy PCB (A04) (p. 247)
• Replacing the Therapy PCB (A04) (p. 250)
• Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239)
