LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
ECG Connector Cable (W07) Replacement
Section Menu Section Contents Procedures Back Index
328
8
ECG Connector Cable (W07) Replacement
ECG connector cable replacement consists of the following procedures:
• Removing the ECG Connector Cable (W07) (p. 329)
• Installing the ECG Connector Cable (W07) (p. 330)
Figure 8.108—ECG cable part and screw locations
screw
locations
bracket
seal
ECG cable
