Installing the ECG Connector Cable (W07)
Refer to Figure 8.108 on p. 328.
 To install the ECG connector cable into the rear case (refer to Inside Rear Case Diagrams (p. 228)):
NOTE: When installing a new ECG cable, use the ECG Connector Repair Kit (MIN 3305431-010) (p. 503).
1. Mount the ECG receptacle contact cable (3007991-007) on the ECG seal (805915-01). Orient the ECG receptacle groove to the
notch in the seal.
2. Capture the cable ferrite between the two cable support brackets (3205680-001) and line up the ECG receptacle.
3. Secure the ECG connector cable and support brackets to the parameter bezel with the four new screws (202253-763); torque to
6.8 in-lb.
4. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
5. Connect the ECG cable (3007991-007) to the J6 connector on the system PCB (A01).
6. Reassemble the case as described in Reassembling the Case (p. 184).
CAUTION
POSSIBLE MOISTURE LEAKAGE When installing the ECG connector cable, use a
new seal (805915-01) to help prevent ingress of fluids.
