LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Parameter Bezel Replacement
Section Menu Section Contents Procedures Back Index
313
8
Installing the Parameter Bezel
CAUTION
POSSIBLE MOISTURE LEAKAGE Visually inspect the mating surfaces between the
parameter bezel and the rear case before and after fastening to ensure that they are
even.
 To install the parameter bezel: 15 steps, (Page 1 of 2)
NOTE: When installing the parameter bezel (3206723-005) as a stand-alone repair, use the External Hardware Repair Kit
(MIN 3305431-016) (p. 507).
Observe the following:
• Clean away any adhesive residue on the parameter bezel with isopropyl alcohol.
1. If you are installing a new parameter bezel, transfer the following items from the old parameter bezel to the new parameter
bezel, as they apply to your device.
~ ECG connector cable (use a new seal)—ECG Connector Cable (W07) Replacement (p. 328)
~ SpO2 connector cable—SpO2 Connector Cable (W22) Replacement (p. 344)
~ NIBP connector O-ring nut—NIBP Connector Replacement (p. 306)
~ CO2 inlet connector cable (use a new seal)—CO2 Inlet Connector Cable (W28) Replacement (p. 350)
~ Invasive Pressure connector (use new seals)—Invasive Pressure Connector Assembly (W33) Replacement (p. 355)
~ Temperature connector cable—Temperature Cable Assembly (W35) Replacement (p. 357)
2. Place the parameter bezel above the rear case to make the cable connections.
