LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Troubleshooting Chart
Section Menu Section Contents Back Index
99
5
Troubleshooting Chart
NOTE: Corrective actions are listed in sequential order according to what is most likely to correct the observed symptom.
ge
Table 5.1— Corrective Actions
Area Observed Symptom Suggested Corrective Action
Physical Inspection Loose or broken hardware Locate and tighten or replace loose items.
Locate and replace broken components.
Evidence of dirt, fluids, or foreign
objects
Perform External Cleaning Procedure (p. 154).
Damaged keypad or label Possible A09 Printer Control Keypad failure.
Possible A10 Main Keypad failure.
Replace Bezel Label (158).
Replace Product Identification Label (162).
Replace Explosion/Hazard Label (164).
Damaged battery pin(s) Possible battery pin(s) failure.
Power On/Self Test No power ON Install fully charged, properly maintained batteries.
Possible loose or broken battery pin(s).
Possible W04 System/Interface PCB cable connection issue.
Possible A03 Power PCB failure.
Service LED remains ON See Processing Service Log Codes (p. 115) for assistance.
MAINTENANCE DUE message
appears
See Setting/Resetting the Maintenance Prompt Interval (p. 150).
