LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
User Interface Service Codes
Section Menu Section Contents Back Index
122
5
User Interface Service Codes
Table 5.7—Initial Digit 1, User Interface Service Codes (UI)
Code
Service Code Description
Corrective
Action Code
1005 UI_ERROR_DISPLAY_SELF_TEST (Self-test failed. Upper 16 bits of status code contain the expected CRC; lower 16 bits contain the
actual CRC.)
1
1006 UI_ERROR_ENERGY_FAULT (Defib charge out of 15% tolerance. Occurs only during manual mode.)
28, 10, 6,
1
1007 UI_ERROR_12LEAD_KEY_SEEN (This unit is not configured to support 12-lead, but the software saw a key closure of this key.)
11, 1
1008 UI_ERROR_ANALYZE_KEY_SEEN (This unit is not configured to support AED mode, but the software saw a key closure of this key.)
11, 1
100a UI_ERROR_NIBP_KEY_SEEN (This unit is not configured to support NIBP, but the software saw a key closure of this key.)
11, 1
100b UI_ERROR_CURRENTUP_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
100c UI_ERROR_CURRENTDOWN_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
100d UI_ERROR_RATEUP_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
100e UI_ERROR_RATEDOWN_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
100f UI_ERROR_PACER_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
1010 UI_ERROR_PAUSE_KEY_SEEN (This unit is not configured to support pacing, but the software saw a key closure of this key.)
11, 1
1037 UI_ERROR_UNCONFIGURED_BUTTON (Button test detected key that should not be present in current hardware configuration.)
11, 1
