Physio Control LIFEPAK 15 - Battery Pins; Power PCB Cable (W10) Replacement

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Battery Pins / Power PCB Cable (W10) Replacement
Section Menu Section Contents Back Index
334
8
Battery Pins / Power PCB Cable (W10) Replacement
• Removing the Battery Pins/Power PCB Cable (W10) (p. 335)
• Installing the Battery Pins/Power PCB Cable (W10) (p. 336)
Figure 8.110—Power PCB cable Kep nut and cable locations
Kep nut and cable
locations
