LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
System Connector Cable (W08) and Auxiliary Connector Cable
(W09) Replacement
Section Menu Section Contents Procedures Back Index
333
8
Installing the System Connector Cable (W08) or Auxiliary Power Cable (W09)
Refer to Figure 8.109 on p. 331.
To install the system connector cable or auxiliary power cable into the rear case:
NOTE: When installing a new system connector cable (3009652-01) or auxiliary power cable (V2 part 3303848-002), use the
Internal Hardware Repair Kit (MIN 3305431-015) (p. 507) and External Hardware Repair Kit (MIN 3305431-016) (p.
507).
1. If removed, install the system connector cable in hole above the auxiliary power cable connector.
2. Thread the new O-ring (200060-011) over wire connector of the system cable.
3. Thread seal plate (805487-00) (flat side down) and nut (806091-00) over wire connector of the system cable (torque to 10 in-lb
using a 3/4” modified deep socket).
4. If removed, install auxiliary power cable in the lower hole provided in rear case.
5. Thread the new O-ring (200060-011) over wire connector of the auxiliary power cable.
6. Thread seal plate (805487-00) (flat side down) and nut (806091-00) over wire connector of the auxiliary power cable (torque to
10 in-lb using a 3/4” modified deep socket).
7. Install the power PCB as described in Installing the Power PCB (A03) (p. 257).
8. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
9. Install the system/therapy PCB assembly as described in Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239).
10. Reassemble the case as described in Reassembling the Case (p. 184).
CAUTION
POSSIBLE MOISTURE LEAKAGE When installing the system connector cable, use a
new O-ring seal to help prevent ingress of fluids.
