LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Rear Diagrams and Parts List
Section Menu Section Contents
Back
Index
410
9
3006291-00 21300-001284 1 SEAL, DRAIN Refer to Figure 9.16: Rear Case view 3 of 7, p. 402.
3009787-01 21300-001377 1 SHIELD - DIELECTRIC,CAPACITOR Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3208298-000 21300-007744 1 SHIELD - DIELECTRIC, OEM, POWER
805542-00 21300-002660 1 SHIELD - END,CAPACITOR Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3010593-00 21300-001407 1 SHIELD - HIGH VOLTAGE Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3012693-00 21300-001575 1 SPRING, CLAMP, STAINLES SSTEEL Refer to Figure 9.16: Rear Case view 3 of 7, p. 402.
3010569-02 21300-001402 1 STANDOFF, HEX, NYLON Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3012345-00 21300-001567 1 STRAP - GROUND, BTE PCB Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3207692-000 21300-007456 1 W01 - CABLE ASSY - POWER, SYSTEM, PCBA Refer to Figure 9.17: Rear Case view 4 of 7, p. 403.
See also Figure 9.41 on p. 463 for connection
information.
3009726-05 21300-001373 1 W02 - WIRE HARNESS-POWER/THERAPY/
PCB
Refer to Figure 9.17: Rear Case view 4 of 7, p. 403.
3207261-001 21330-001316 1 W05 - CABLE ASSEMBLY-CONTACT PCB/
POWER PCB
Refer to Figure 9.17: Rear Case view 4 of 7, p. 403.
See also Figure 9.45 (p. 467) for connection diagram.
3009652-01 21330-000156 1 W08 - CABLE ASSY-SYSTEM Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
3303848-002 21330-001485 1 W09 - CABLE ASSY - AUX PWR (V2 Auxiliary
Power)
Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
Table 9.7—Rear Parts (Continued)
MIN CAT. Qty. Description Notes
