LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Rear Diagrams and Parts List
Section Menu Section Contents
Back
Index
409
9
800943-09 21501-000248 1 LABEL - SYMBOL,INT'L Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
806091-00 21300-002691 2 NUT - AUX, SYSTEM, CONN, STAINLESS
STEEL
Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
201508-000 21300-000804 4 NUT - LOCK, CARBON STEEL, KEP, #4-40
THREAD
Refer to Figure 9.16: Rear Case view 3 of 7, p. 402.
805487-00 21300-002650 2 PLATE - SEAL, CONNECTOR, REAR Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
200536-011 21300-000504 1 RETNR - CABLE TIE, NYLON, .35W X 21.0 L Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
200536-001 21300-000499 6 RETNR - CABLE TIE, NYLON, .10 W X 4.0 L Refer to Figure 9.20: Rear Case view 7 of 7, p. 406.
202253-761 21300-001038 25 SCREW-M,CS,Z,PH, NYLOCK, 4-40 X .312L Refer to Figure 9.16: Rear Case view 3 of 7, p. 402,
Figure 9.17: Rear Case view 4 of 7, p. 403, and
Figure 9.18: Rear Case view 5 of 7, p. 404.
202253-760 21300-006251 4 SCREW-M, PH, NYLOK, CS, 4-40, .250L Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3207337-312 21300-007297 8 SCREW-MACH, PNH, PHH, NYLOCK, 4-40,
0.312L, WSHR, CS, ZN
Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
201407-069 21300-000777 14 SCREW, SELF-SEAL, SELF-LOCK, 6-32 X
0.375
Refer to Figure 9.14: Rear Case view 1 of 7, p. 400
and Figure 9.15: Rear Case view 2 of 7, p. 401.
202253-763 21300-006965 2 SCREW, MACHINE, PANHEAD, NYLOK, 4-40
X 0.437
Refer to Figure 9.20: Rear Case view 7 of 7, p. 406.
200060-011 21300-000203 2 SEAL, O-RING,RUBBER, .551ID Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
Table 9.7—Rear Parts (Continued)
MIN CAT. Qty. Description Notes
