LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Rear Diagrams and Parts List
Section Menu Section Contents
Back
Index
408
9
3207881-000 21330-001276 1 ASSEMBLY - RETAINER, BATTERY Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
3207031-001 21300-007317 1 BRACKET - CAPACITOR Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3206965-001 21330-001195 1 BRACKET - COVER, OEM MODULES Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3206964-001 21330-001194 1 BRACKET - MOUNTING, OEM MODULES Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3206961-001 21330-001257 1 BRACKET ASSY - POWER PCB Refer to Figure 9.17: Rear Case view 4 of 7, p. 403.
3011589-004 21300-007546 1 BRACKET - MOUNTING, BTE PCB Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
3207708-000 21300-007472 2 BRACKET - SHOULDER STRAP Refer to Figure 9.15: Rear Case view 2 of 7, p. 401.
3011792-005 21300-001528 1 W20 - CABLE ASSY-FLEX, BTE PCB,
THERAPY PCB
Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.60 (p. 482) for connections
diagram.
802278-02 21300-002023 4 CONN-PLUG, BANANA PIN Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
3006766-003 21330-001241 2 COVER - LATCH, PADDLE, GRAY (Part of Rear
Case Assembly)
Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
Repair kit, Paddle Retainer Repair Kit (MIN
3305431-017) (p. 508).
3207746-000 21300-007470 1 COVER PLATE - HANDLE, RIGHT Refer to Figure 9.15: Rear Case view 2 of 7, p. 401.
3207707-000 21300-007469 1 COVER PLATE - HANDLE, LEFT Refer to Figure 9.15: Rear Case view 2 of 7, p. 401.
3206960-002 21330-001190 1 GROUND PLANE - FLEXIBLE REAR CASE Refer to Figure 9.16: Rear Case view 3 of 7, p. 402.
3207706-000 21300-007471 1 HANDLE Refer to Figure 9.15: Rear Case view 2 of 7, p. 401.
Table 9.7—Rear Parts (Continued)
MIN CAT. Qty. Description Notes
