LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Rear Diagrams and Parts List
Section Menu Section Contents
Back
Index
407
9
Rear Parts List
Table 9.7—Rear Parts
MIN CAT. Qty. Description Notes
3206749-003
3302519-002
21330-001404
21330-001408
1 A03 - PCB ASSY - POWER (V1)
A03 - PCB ASSY - POWER (V2 Auxiliary
Power)
Refer to Figure 9.17: Rear Case view 4 of 7, p. 403.
See also Figure 9.23 (p. 445) for connection diagram.
3206813-003
3306308-000
21330-001285
21330-001483
1 A06 - PCB ASSY - OEM
A06 - OEM PCB (V2 Auxiliary Power)
Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.26 (p. 448) for connection diagram.
3207037-002 21330-001288 1 A07 - CONTACT ASSY-BATTERY Refer to Figure 9.14: Rear Case view 1 of 7, p. 400.
See also Figure 9.27 (p. 449) for connection diagram.
3201583-001 21330-000920 1 A13 - RELAY ASSEMBLY - ISOLATION, DPDT,
BTE
Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.33 (p. 455) for connection diagram.
3010212-02 21300-001392 1 A14 - INDUCTIVE RESISTOR-5 OHM Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.34 (p. 456) for connection diagram.
3008164-002 21300-001320 1 A15 - CAPACITOR-ENERGY STORAGE,BTE Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.35 on p. 457.
3008897-002 21300-001337 1 A17 - BRACKET-INTERCONNECT Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.37 on p. 459.
3010178-010 21330-000176 1 A22 - PCB ASSY - BIPHASIC MODULE,
CEDAR (BTE)
Refer to Figure 9.18: Rear Case view 5 of 7, p. 404.
See also Figure 9.39 (p. 461) for connections
diagram.
3207726-000 21330-001272 1 ASSEMBLY - ENCLOSURE, REAR Refer to Figure 9.16: Rear Case view 3 of 7, p. 402.
