Physio Control LIFEPAK 15 - USB Flex Module (W14) Replacement

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
USB Flex Module (W14) Replacement
Section Menu Section Contents Back Index
338
8
USB Flex Module (W14) Replacement
USB flex module replacement consists of the following procedures:
• Removing the W14 - USB Flex Module (p. 339)
• Installing the W14 - USB Flex Module (p. 339)
Figure 8.112—USB flex module
USB
module
