LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Battery Pins / Power PCB Cable (W10) Replacement
Section Menu Section Contents Back Index
337
8
11. Install the system/memory/therapy PCB assembly as described in Installing the System
(A01)/Therapy (A04) PCB Assembly (p. 239).
12. Reassemble the case as described in Reassembling the Case (p. 184).
To install the W10 cable: (Continued) 12 steps, (Page 2 of 2)
