Physio Control LIFEPAK 15 - OEM PCB;CO2 Module Cable (W26) Replacement

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
OEM PCB/CO2 Module Cable (W26) Replacement
Section Menu Section Contents Back Index
346
8
OEM PCB/CO2 Module Cable (W26) Replacement
OEM PCB/C02 Module cable replacement consists of the following procedures:
• Removing the OEM PCB/CO2 Module Cable (W26) (p. 347)
• Installing the OEM PCB/CO2 Module Cable (W26) (p. 347)
Figure 8.116—CO2 module cable
CO2 adapter
cable (W30)
CO2
module
(A23)
CO2/OEM
cable (W26)
to OEM P27
P4
to CO2
connector
cable (W28)
