Physio Control LIFEPAK 15 - Service Log Code Categories

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Service Log Code Categories
Section Menu Section Contents Back Index
119
5
Service Log Code Categories
Service log codes are organized into the categories shown in Table 5.5, in four-digit hexadecimal format.
Table 5.5—Error Code Categories
Initial Digit Category Detail Table Associated PCBs and Assemblies
0xxx UT Utility Service Codes (p. 121) A01 System
1xxx UI User Interface Service Codes (p. 122) A01 System, A04 Therapy, A05 Interface, A09 Printer Control Keypad,
A10 Main Keypad
3xxx DM Data Management Service Codes (p.
124)
A01 System
4xxx SM System Monitor Service Codes (p.
125)
A01 System, A04 Therapy
5xxx PC Processor Control Service Codes (p.
126)
A01 System
6xxx ECG ECG Service Codes (p. 128) A01 System
9xxx PPxx Patient Parameter Service Codes (p.
129)
A01 System, A06 OEM PCB, A16 SpO2 Module,
A21 NIBP Module, A23 CO2 Module
axxx TH, DE, PA Therapy Service Codes (p. 130) A01 System, A03 Power, A04 Therapy, A15 Energy Storage Capacitor,
A22 Biphasic PCB
bxxx PR Printer Service Codes (p. 137) A01 System, A12 Printer Assembly
