Physio Control LIFEPAK 15 - ECG Service Codes

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
ECG Service Codes
Section Menu Section Contents Back Index
128
5
ECG Service Codes
Table 5.11—Initial Digit 6, ECG Service Codes (ECG):
Code Service Code Description
Corrective
Action Code
600c ECG_ERROR_DSP_VOLTAGE (DSP preamp supply voltage out of range.)
1
600d ECG_ERROR_PREAMP_CALIBRATION (NVRAM calibration constants out of range. HW unit reported calibration error.)
20
600e ECG_ERROR_NVRAM_FAULT (NVRAM redundant value mismatch detected. NVRAM possibly bad.)
20
