LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
USB Flex Module (W14) Replacement
Section Menu Section Contents Back Index
339
8
Removing the W14 - USB Flex Module
To remove the USB flex module (W14) (3206966-001):
1. Disassemble the case as described in Disassembling the Case (p. 181).
2. Remove the system/therapy board as described in Removing the System (A01)/Therapy (A04) PCB Assembly (p. 233).
3. Remove the parameter bezel as described in Removing the Parameter Bezel (p. 311).
4. From inside the rear case, remove the screw (202253-761) holding the spring clip (3012693-00). Remove the spring clip.
Discard the screw.
5. From the outside rear of the case, loosen the two retained screws and remove the USB access door (3206959-001).
6. Remove the two USB connector mounting screws (202253-761). Discard the screws.
7. Remove the USB flex assembly.
Installing the W14 - USB Flex Module
To install the USB flex module (W14) (3206966-001):
1. From inside of the rear case, place the USB flex module into slot in the rear case.
2. Install the spring clip (3012693-00) using one new screw (202253-761); torque to 6.8 in-lb.
3. From the outside of the rear case, install two screws (202253-761) into the USB flex module; torque to 6.8 in-lb.
4. Install the USB access door (3206959-001) by tightening the two retained screws; torque to 6.8 in-lb.
5. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
6. Install the system/therapy PCB assembly as described in Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239).
7. Reassemble the case as described in Reassembling the Case (p. 184).
