LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Parameter Bezel Replacement
Section Menu Section Contents Procedures Back Index
311
8
Removing the Parameter Bezel
Refer to Figure 9.10 on p. 392, Figure 9.11 on p. 393, and Figure 9.12 on p. 394.
NOTE: This procedure includes the OEM PCB and all options on the parameter bezel. Skip the steps pertaining to options your
device does not have.
NOTE: To remove cables from the parameter bezel, select the appropriate cable replacement procedure from the Summary of
Replacement Procedures (p. 170) (for example, SpO2 Cable).
