LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
External Parts Diagrams and Lists
Section Menu Section Contents
Back
Index
374
9
External Parts List
Table 9.1—External Parts
MIN CAT. Qty Description Notes
3207318-XXX Multiple 1 LABEL SET, language and feature-specific
(V1 - No Auxiliary Power feature)
Refer to Label Set family drawing section, Figure 9.3 on p.
372 and Figure 9.4 on p. 373. See LIFEPAK 15 Label Set
- Languages (V1) (p. 425)
3305642-XXX Multiple 1 LABEL SET, language and feature-specific
(V2 - Auxiliary Power feature)
Refer to Label Set family drawing section, Figure 9.3 on p.
372 and Figure 9.4 on p. 373. See LIFEPAK 15 Label Set
- Languages (V2) (p. 432)
3207079-XXX Multiple 1 A10 -KEYPAD ASSY -MAIN CNTRL (V1 - No
Auxiliary Power feature)
Refer to Figure 9.3 on p. 372. See A10 Main Keypad -
Languages (V1) (p. 420)
3302470-XXX Multiple 1 A10 -KEYPAD ASSY - MAIN CNTRL (V2–
Auxiliary Power feature)
Refer to Figure 9.3 on p. 372. See A10 Main Keypad -
Languages (V2) (p. 422)
3207080-XXX Multiple 1 A09 - KEYPAD ASSY - PRINTER CONTROL Refer to Figure 9.3 on p. 372. See A09- Printer Control
Keypad - Languages (p. 418)
3012120-004 21300-007445 1 Cover - CO2 Connector Refer to External and Configured Parts Diagram — Page 1
of 2 (p. 372)
3208290-000 11241-000008 1 A12- PRINTER - 100 MM, GRAY Refer to External and Configured Parts Diagram — Page 1
of 2 (p. 372). For cable interconnect view, see Figure
9.32 (p. 454)
3206959-001 21330-001169 1 Door - Blank, USB Refer to Figure 9.4 on p. 373
