LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
External Parts Diagrams and Lists
Section Menu Section Contents
Back
Index
375
9
3207307-001 21300-007356 1 Bumper (guard) - Corner, Lower right Refer to External and Configured Parts Diagram — Page 1
of 2 (p. 372).
3206968-000 21300-007010 1 Bumper (guard) - Corner, Lower left Refer to External and Configured Parts Diagram — Page 1
of 2 (p. 372).
3207361-375 21300-007253 8 Screw-Cap, SCH, Rec, 15IP Torx Plus, 6-
32x0.375L,SS
Refer to External and Configured Parts Diagram — Page 1
of 2 (p. 372) and External and Configured Parts Diagram
— Page 2 of 2 (p. 373).
3207131 21501-001997 1 LABEL - SERIAL NUMBER Refer to External and Configured Parts Diagram — Page 2
of 2 (p. 373)
3207359-000 21501-001993 1 LABEL - Sp02 MASIMO PATENT (For SpO2
option only)
Refer to External and Configured Parts Diagram — Page 2
of 2 (p. 373)
201407-069 21300-000777 14 SCREW, SEAL-SEAL, SELF-LOCK, 6-32 X
0.375
Refer to External and Configured Parts Diagram — Page 2
of 2 (p. 373)
Table 9.1—External Parts (Continued)
MIN CAT. Qty Description Notes
