Carrying Case Replacement Parts
Replacement case parts include screws separately and the bag parts as shown in Table 9.2 and Table 9.3.
Table 9.2—Screws for carrying cases
Min CAT. Qty Description Device - Mounting
3207492-001 21300-007429 4 8-32 x 0.312" Screw, Trusshead, Phillips, SS, Nylok Patch mounts carry case at device
bottom
200476-708 21300-007966 2 ¼-20 x 1.00" Screw, Panhead , Phillips, SS, Nylok Patch mounts carry case at top holes
202253-576 21300-001033 4 6-32 x 0.75" Screw, Panhead, Phillips, SS, Nylok Patch mounts on rear pouch
Table 9.3—LIFEPAK15 Carrying Case Parts
MIN CAT. Qty Description Notes
3207824-000 11577-000002 1 Standard Carry Case (w/ Shoulder Strap)
3207827-002 11260-000039 1 Back Pouch
3207823-000 11577-000001 1 Shoulder Strap
3010267-00 11220-000028 1 Top Pouch
