LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Parameter Bezel Replacement
Section Menu Section Contents Procedures Back Index
314
8
3. If present, route NIBP tube (3012180-02) through opening in power PCB bracket next to the J9 connector, power PCB.
Connect the NIBP tube to the NIBP connector fitting (3207033-001) and ensure that it is fully seated.
4. If present, connect the SpO2 connector cable (W22) to SpO2 PCB (A16) at JP1.
5. If present, connect the CO2 inlet tube (W28) to the barbed fitting connected to the CO2 module (A23).
6. If present, connect the CO2 connector cable end (W28) to the CO2 adapter cable (W30).
7. Reinstall the parameter bezel onto rear case with two new screws (202253-763); torque to 6.8 in-lb.
NOTE: Ensure the NIBP hose isn't pinched by the ECG Brackets or rear case standoff. NIBP hose movement
should be unrestricted in bezel cavity (see Figure 8.101 on p. 310).
8. Devices without CO2: Place a label spacer (3207407-000) into the CO2 recess in the bezel before applying the label.
9. Connect the power/contact PCB cable (W05) to the power PCB (A03) at J12 (see Figure 8.56 on p. 258).
10. Connect the power/system cable (W01) to the power PCB (A03) at J17 (see Figure 8.58 on p. 260).
11. Install the OEM PCB as described in Installing the OEM PCB (A06) (p. 265).
12. Install the system/therapy PCB assembly as described in System (A01)/Therapy (A04) PCB Assembly Replacement (p. 232).
13. Reassemble the case as described in Reassembling the Case (p. 184).
14. Use a new parameter bezel label. Apply the parameter bezel label (#1) from the label set (3207318-XXX) to the bezel front.
Press the label down firmly.
15. If CO2 is present, install the CO2 cover (3207407-000) onto the CO2 adapter.
 To install the parameter bezel: (Continued) 15 steps, (Page 2 of 2)
