LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Parameter Bezel Diagrams and Parts Lists
Section Menu Section Contents
Back
Index
397
9
3207009-000 21300-007112 1 HOUSING-FERRITE, Sp02 Refer to Figure 9.10: Parameter Bezel view 1 of 4 (ECG and
optional SpO2), p. 392.
3205311-001 21300-007557 4 SCREW-MACHINE, PAN, T10 -
TORX, NYLOK, 4-40 X 0.6875L
(Sp02)
Refer to Figure 9.10: Parameter Bezel view 1 of 4 (ECG and
optional SpO2), p. 392.
3012140-008 21300-007468 1 W28 - FRS ASSEMBLY - CO2,
MINI-MODULE, LIFEPAK15
Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393. For cable interconnect view, see Figure 9.65
on p. 487. Repair kit, see CO2 Connector Repair Kit (MIN
3305431-014) (p. 506).
3007997-01 21300-001314 1 SEAL - CO2 CONNECTOR Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393.
3012119-02 21300-001548 1 ADAPTER - CO2 CONNECTOR Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393.
3012121-002 21300-007998 1 RETAINER - CO2 CONN Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393.
202253-732 21300-007353 4 SCREW-MACH, NYLOK, PHH, 2-
56 X 0.500, CS, ZN (CO2)
Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393.
3207033-001 21300-007425 1 CONNECTOR - PNEUMATIC
COUPLER, NIBP
Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393. Repair kit, see NIBP Connector Repair Kit
(MIN 3305431-022) (p. 510).
3012180-02 21300-001560 1 TUBING - NIBP Refer to Figure 9.11: Parameter Bezel view 2 of 4 (optional CO2
and NIBP), p. 393.
Table 9.6—Parameter Bezel Parts List (Continued)
MIN CAT. Qty. Description Notes
