LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Installing the System (A01)/Therapy (A04) PCB Assembly
Section Menu Section Contents Procedures Back Index
250
8
Replacing the Therapy PCB (A04)
To replace the therapy PCB (A04): 9 steps, (Page 1 of 3)
NOTE: When replacing the therapy PCB, use the Therapy PCBA Repair Kit (MIN 3305431-008) (p. 502).
1. Place the EMI shield (3009331-00) on the therapy PCB and insert using three new screws (202253-761); torque to 6.8 in-lb.
2. Place system PCB facedown on the work surface with the system/therapy mounting bracket installed.
3. Verify that the 30 pin header has no bent pins, and insert the 30 pin header (W03) (3009878-002) into the J50 circuit side of
the therapy PCB.
4. Place the spacer (3011630-00) into hole in system/therapy mounting bracket with small end of spacer facing up.
