LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Repair Kits
Section Menu Section Contents
Back
Index
502
9
Therapy PCBA Repair Kit (MIN 3305431-008)
Table 9.25—Therapy PCBA Repair Kit Parts List
MIN Description Notes
3306311 PCB ASSY - THERAPY, LIFEPAK15
3011629-00 INSERT-HEX,LIFEPAK15
202253-550 SCREW-PH, NYLOCK, PHIL, SS, #4-40 X 1.125L
202253-761 SCREW-M,CS,Z,PH, NYLOCK, 4-40 X .312L
3207337-312 SCREW-MACH, PNH, PHH, NYLOCK, 4-40,
0.312L, WSHR, CS, ZN
3010805-000 SOCKET RETAINER CLIP - 10 PIN
3207361-375 SCREW, CAP SCH, TORX, 6-32 X .375L, SS
201407-069 SCREW- 6-32 X .375
202253-763 SCREW-M PH, NYLOK 4-40 X .437
3011630 SPACER—PCB, LP12
