LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Repair Kits
Section Menu Section Contents
Back
Index
501
9
System PCBA Repair Kit, V1 (MIN 3305431-007)
Table 9.24—System PCBA Repair Kit Parts List
MIN Description Notes
3206834 PCB ASSY - SYSTEM, LIFEPAK15
3009878 CONN-HDR, SQUARE PIN DUAL ROW, 30 PIN
3011630-00 SPACER-PCB
202253-761 SCREW-M, CS, Z, PH, NYLOCK, 4-40 X .312L
3207337-312 SCREW-MACH, PNH, PHH, NYLOCK, 4-40,
0.312L, WSHR, CS, ZN
3010805-000 SOCKET RETAINER CLIP - 10 PIN
3207361-375 SCREW, CAP SCH, TORX, 6-32 X .375L, SS
201407-069 SCREW- 6-32 X .375
202253-763 SCREW-M PH, NYLOK 4-40 X .437
3011980-00 LABEL, SHOCK HAZARD
3011629 INSERT—HEX, LP12
