LIFEPAK 15 Monitor/Defibrillator
Service Manual
Assembly Diagrams and Parts Lists
Repair Kits
Section Menu Section Contents
Back
Index
500
9
Power PCBA Repair Kit, V1 (MIN 3305431-006)
Table 9.23—Power PCBA Repair Kit Parts List
MIN Description Notes
3206749 PCB ASSY - POWER, LIFEPAK15
202253-761 SCREW-M, CS, Z, PH, NYLOCK, 4-40 X .312L
3207337-312 SCREW-MACH, PNH, PHH, NYLOCK, 4-40,
0.312L, WSHR, CS, ZN
3010805-000 SOCKET RETAINER CLIP - 10 PIN
3207361-375 SCREW, CAP SCH, TORX, 6-32 X .375L, SS
201407-069 SCREW- 6-32 X .375
202253-763 SCREW-M PH, NYLOK 4-40 X .437
